Classification of welding process

welding a fabrication process

WHAT IS WELDING
Welding Definition 1 - welding is the process of joining different materials.
welding produces a union of material by heating them to suitable temperature, with or without the application of pressure or by the application of pressure alone with or without filler metal.

Welding Definition 2 - Welding is process of joining two similar or dissimilar metals using heat to melt and fuse them together permanently with and without application of pressure & with or without using filler metal.

WELDING JOINT


PROCESS OF WELDING

ADVANTAGES OF WELDING

  • gives freedom in design.
  • gives portability with selected instruments.
  • a good weld is as strong as parent metal.
  • general welding equipment are not costly.
  • large no of metals and alloys  both similar and dissimilar can be welded .
  • it can be mechanized and automated.

DISADVANTAGES OF WELDING

  • it results in residual stresses and distortion.
  • gives harmful radiations,fumes and spatters.
  • jigs and fixtures are required to hold and position the work piece to be welded.
  • fixtures required for distortion control.
  • edge preparation is required.
  • it needs stress relief heat treatment like preheating postheating etc.
  • skilled welder is required
  • the structure of weld is not the same as that of base metal.
  • welding requires various testings. NDT and DT



CLASSIFICATION / TYPES OF WELDING
welding is classified on the basis of
  • source of heat i.e. flame,arc etc.
  • based on the interaction
  • i)solid state welding  ii)liquid state welding(fusion welding)
In general various welding processes are classified as follows

1-ARC WELDING
  • Carbon arc welding
  • flux cored arc welding
  • shielded metal arc welding
  • submerged arc welding
  • TIG or GTAW(gas tungstun arc welding)
  • MIG or GMAW(gas metal arc welding)
  • Plasma arc welding
  • Electroslag weling and electro gas welding
  • Stud arc welding

2-GAS WELDING
  • Air-acetylene welding
  • Oxy-acetylene welding
  • Oxy-hydrogen welding
  • Pressure gas welding
    3-RESISTANCE WELDING
    • Spot welding
    • Seam welding
    • Projection welding
    • Resistance butt welding
    • Flash butt welding
    • Percussion welding
    • High frequency resistance wel,ding
    4-RADIANT ENERGY WELDING PROCESSES
    • Electron beam welding
    • Laser beam welding
    5-SOLID STATE WELDING
    • Cold welding
    • Diffusion welding
    • Explosive welding
    • Forge welding
    • Friction welding
    • Hot pressure welding
    • Roll welding
    • Ultrasonic welding
    6-THERMO-CHEMICAL WELDING PROCESSES
    • Thermit welding
    • Atomic hydrogen welding
